Google ADK 与 LiteLLM

将 Google ADK 与 LiteLLM Python SDK、LiteLLM Proxy 结合使用

本教程展示了如何使用 Agent Development Kit (ADK) 构建智能代理，并借助 LiteLLM 支持多个大型语言模型 (LLM) 提供商。

概述

ADK (Agent Development Kit) 允许你构建由 LLM 提供支持的智能代理。通过与 LiteLLM 集成，你可以

• 使用多个 LLM 提供商（OpenAI、Anthropic、Google 等）
• 轻松切换不同提供商的模型
• 连接到 LiteLLM 代理以进行集中模型管理

先决条件

• Python 环境设置
• 模型提供商的 API 密钥（OpenAI、Anthropic、Google AI Studio）
• 对 LLM 和代理概念的基本了解

安装

安装依赖项

pip install google-adk litellm

1. 设置环境

首先，导入必要的库并设置你的 API 密钥

设置环境和 API 密钥

import os
import asyncio
from google.adk.agents import Agent
from google.adk.models.lite_llm import LiteLlm  # For multi-model support
from google.adk.sessions import InMemorySessionService
from google.adk.runners import Runner
from google.genai import types
import litellm  # Import for proxy configuration

# Set your API keys
os.environ["GOOGLE_API_KEY"] = "your-google-api-key"  # For Gemini models
os.environ["OPENAI_API_KEY"] = "your-openai-api-key"  # For OpenAI models
os.environ["ANTHROPIC_API_KEY"] = "your-anthropic-api-key"  # For Claude models

# Define model constants for cleaner code
MODEL_GEMINI_PRO = "gemini-1.5-pro"
MODEL_GPT_4O = "openai/gpt-4o"
MODEL_CLAUDE_SONNET = "anthropic/claude-3-sonnet-20240229"

2. 定义一个简单工具

创建一个你的代理可以使用的工具

天气工具实现

def get_weather(city: str) -> dict:
    """Retrieves the current weather report for a specified city.

    Args:
        city (str): The name of the city (e.g., "New York", "London", "Tokyo").

    Returns:
        dict: A dictionary containing the weather information.
              Includes a 'status' key ('success' or 'error').
              If 'success', includes a 'report' key with weather details.
              If 'error', includes an 'error_message' key.
    """
    print(f"Tool: get_weather called for city: {city}")

    # Mock weather data
    mock_weather_db = {
        "newyork": {"status": "success", "report": "The weather in New York is sunny with a temperature of 25°C."},
        "london": {"status": "success", "report": "It's cloudy in London with a temperature of 15°C."},
        "tokyo": {"status": "success", "report": "Tokyo is experiencing light rain and a temperature of 18°C."},
    }

    city_normalized = city.lower().replace(" ", "")

    if city_normalized in mock_weather_db:
        return mock_weather_db[city_normalized]
    else:
        return {"status": "error", "error_message": f"Sorry, I don't have weather information for '{city}'."}

3. 代理交互的辅助函数

创建一个辅助函数以促进代理交互

代理交互辅助函数

async def call_agent_async(query: str, runner, user_id, session_id):
    """Sends a query to the agent and prints the final response."""
    print(f"\n>>> User Query: {query}")

    # Prepare the user's message in ADK format
    content = types.Content(role='user', parts=[types.Part(text=query)])

    final_response_text = "Agent did not produce a final response."

    # Execute the agent and find the final response
    async for event in runner.run_async(
        user_id=user_id,
        session_id=session_id,
        new_message=content
    ):
        if event.is_final_response():
            if event.content and event.content.parts:
                final_response_text = event.content.parts[0].text
            break

    print(f"<<< Agent Response: {final_response_text}")

4. 将不同模型提供商与 ADK 结合使用

4.1 使用 OpenAI 模型

OpenAI 模型实现

# Create an agent powered by OpenAI's GPT model
weather_agent_gpt = Agent(
    name="weather_agent_gpt",
    model=LiteLlm(model=MODEL_GPT_4O),  # Use OpenAI's GPT model
    description="Provides weather information using OpenAI's GPT.",
    instruction="You are a helpful weather assistant powered by GPT-4o. "
                "Use the 'get_weather' tool for city weather requests. "
                "Present information clearly.",
    tools=[get_weather],
)

# Set up session and runner
session_service_gpt = InMemorySessionService()
session_gpt = session_service_gpt.create_session(
    app_name="weather_app",
    user_id="user_1",
    session_id="session_gpt"
)

runner_gpt = Runner(
    agent=weather_agent_gpt,
    app_name="weather_app",
    session_service=session_service_gpt
)

# Test the GPT agent
async def test_gpt_agent():
    print("\n--- Testing GPT Agent ---")
    await call_agent_async(
        "What's the weather in London?",
        runner=runner_gpt,
        user_id="user_1",
        session_id="session_gpt"
    )

# Execute the conversation with the GPT agent
await test_gpt_agent()

# Or if running as a standard Python script:
# if __name__ == "__main__":
#     asyncio.run(test_gpt_agent())

4.2 使用 Anthropic 模型

Anthropic 模型实现

# Create an agent powered by Anthropic's Claude model
weather_agent_claude = Agent(
    name="weather_agent_claude",
    model=LiteLlm(model=MODEL_CLAUDE_SONNET),  # Use Anthropic's Claude model
    description="Provides weather information using Anthropic's Claude.",
    instruction="You are a helpful weather assistant powered by Claude Sonnet. "
                "Use the 'get_weather' tool for city weather requests. "
                "Present information clearly.",
    tools=[get_weather],
)

# Set up session and runner
session_service_claude = InMemorySessionService()
session_claude = session_service_claude.create_session(
    app_name="weather_app",
    user_id="user_1",
    session_id="session_claude"
)

runner_claude = Runner(
    agent=weather_agent_claude,
    app_name="weather_app",
    session_service=session_service_claude
)

# Test the Claude agent
async def test_claude_agent():
    print("\n--- Testing Claude Agent ---")
    await call_agent_async(
        "What's the weather in Tokyo?",
        runner=runner_claude,
        user_id="user_1",
        session_id="session_claude"
    )

# Execute the conversation with the Claude agent
await test_claude_agent()

# Or if running as a standard Python script:
# if __name__ == "__main__":
#     asyncio.run(test_claude_agent())

4.3 使用 Google 的 Gemini 模型

Gemini 模型实现

# Create an agent powered by Google's Gemini model
weather_agent_gemini = Agent(
    name="weather_agent_gemini",
    model=MODEL_GEMINI_PRO,  # Use Gemini model directly (no LiteLlm wrapper needed)
    description="Provides weather information using Google's Gemini.",
    instruction="You are a helpful weather assistant powered by Gemini Pro. "
                "Use the 'get_weather' tool for city weather requests. "
                "Present information clearly.",
    tools=[get_weather],
)

# Set up session and runner
session_service_gemini = InMemorySessionService()
session_gemini = session_service_gemini.create_session(
    app_name="weather_app",
    user_id="user_1",
    session_id="session_gemini"
)

runner_gemini = Runner(
    agent=weather_agent_gemini,
    app_name="weather_app",
    session_service=session_service_gemini
)

# Test the Gemini agent
async def test_gemini_agent():
    print("\n--- Testing Gemini Agent ---")
    await call_agent_async(
        "What's the weather in New York?",
        runner=runner_gemini,
        user_id="user_1",
        session_id="session_gemini"
    )

# Execute the conversation with the Gemini agent
await test_gemini_agent()

# Or if running as a standard Python script:
# if __name__ == "__main__":
#     asyncio.run(test_gemini_agent())

5. 将 LiteLLM Proxy 与 ADK 结合使用

LiteLLM 代理为多个模型提供统一的 API 端点，简化了部署和集中管理。

使用 litellm 代理所需的设置

变量	描述
LITELLM_PROXY_API_KEY	LiteLLM 代理的 API 密钥
LITELLM_PROXY_API_BASE	LiteLLM 代理的基础 URL
USE_LITELLM_PROXY 或 litellm.use_litellm_proxy	设置为 True 时，你的请求将被发送到 litellm 代理。

LiteLLM 代理集成

# Set your LiteLLM Proxy credentials as environment variables
os.environ["LITELLM_PROXY_API_KEY"] = "your-litellm-proxy-api-key"
os.environ["LITELLM_PROXY_API_BASE"] = "your-litellm-proxy-url"  # e.g., "http://localhost:4000"
# Enable the use_litellm_proxy flag
litellm.use_litellm_proxy = True

# Create a proxy-enabled agent (using environment variables)
weather_agent_proxy_env = Agent(
    name="weather_agent_proxy_env",
    model=LiteLlm(model="gpt-4o"), # this will call the `gpt-4o` model on LiteLLM proxy
    description="Provides weather information using a model from LiteLLM proxy.",
    instruction="You are a helpful weather assistant. "
                "Use the 'get_weather' tool for city weather requests. "
                "Present information clearly.",
    tools=[get_weather],
)

# Set up session and runner
session_service_proxy_env = InMemorySessionService()
session_proxy_env = session_service_proxy_env.create_session(
    app_name="weather_app",
    user_id="user_1",
    session_id="session_proxy_env"
)

runner_proxy_env = Runner(
    agent=weather_agent_proxy_env,
    app_name="weather_app",
    session_service=session_service_proxy_env
)

# Test the proxy-enabled agent (environment variables method)
async def test_proxy_env_agent():
    print("\n--- Testing Proxy-enabled Agent (Environment Variables) ---")
    await call_agent_async(
        "What's the weather in London?",
        runner=runner_proxy_env,
        user_id="user_1",
        session_id="session_proxy_env"
    )

# Execute the conversation
await test_proxy_env_agent()
